Product Description

Applied to industrial heat treatment, electrothermal processing, material manufacturing, aerospace, metallurgy, nonferrous metals, medicine, electronics, food machinery, injection molding machinery, spraying machinery, vacuum coating machines and other equipment. AC power controllers transform and control the AC power between input and output through power electronic devices such as thyristors. Common methods include phase control, cycle control and on-off control.

Main Parameters

Input/output Parameters：

       Voltage：AC 3Φ380V、690V、1kV、2kV（customizable）

       Current：AC300~2000A（customizable）

       Frequency：50Hz

Features：

      Cooling method: water cooling, air cooling

       It integrates power regulation and voltage regulation, and has functions such as phase-locked loop synchronization circuit, automatic phase identification, slow start-up on power-up, slow shutdown, radiator over-temperature detection, over-current protection, current limitation, constant current output, phase loss protection, and remote working status indication.

       Flexible communication mode, supporting multiple communication protocols such as Profinet, Profibus-DP, Modbus-RTU, etc.
