Product Description

It is mainly used for smelting, heat preservation, sintering, welding, quenching, tempering, heat penetration, metal liquid purification, heat treatment, pipe bending, and crystal growth of various metals. Medium frequency induction power supply is a thyristor static converter that converts three-phase AC into single-phase AC. It has strong adaptability to various loads and a wide range of applications. After conversion, the frequency range is 200Hz~8kHz (depending on the working conditions).

Main Parameters

Input Parameters：

 Voltage：AC 3Φ380V

 Frequency：50Hz

Output Parameters：

    Power：25kW，35kW，50kW，75kW，100kW，160kW（customizable）

       Current：48A，66A，90A，120A，180A，275A（customizable）

       Frequency：1~8kHz

Features：

            High reliability, stability, small size and reasonable structure

               With zero start function, when the power grid fluctuates to ±10%, the output is still thermally stable, and when the power grid switches, it has a restart function

               Flexible communication mode, supports multiple communication protocols such as Profinet, Profibus-DP, Modbus-RTU, etc., easy to realize automatic control
